6250 Cryostat Microtome
Trivitron Healthcare
The 6250 Cryostat Microtome provides adjustable sectioning, trimming and specimen-retraction settings for laboratory cryosectioning.
| Specification | Details |
|---|---|
| Model / series | 6250 |
| Trimming thickness range | 1 – 600 µm |
| Trimming thickness | 1 – 50 µm in 5 µm increments |
| Trimming thickness | 50 – 100 µm in 10 µm increments |
| Trimming thickness | 100 – 600 µm in 50 µm increments |
| Section thickness range | 1 – 100 µm |
| Section thickness | 1 – 20 µm in 1 µm increments |
| Section thickness | 20 – 50 µm in 2 µm increments |
| Section thickness | 50 – 100 µm in 5 µm increments |
| Retraction | 0 – 200 µm in 5 µm increments, adjustable |
| Horizontal stroke | 25 ± 1 mm |
| Vertical feed | 59 ± 0.5 mm |
| Forward/backward speed | 300 µm/s (slow), 900 µm/s (fast) |
| Dimensions (W×D×H) | 780 × 700 × 1280 mm, including handwheel |
